Description
Type: Gold Touch 4K*2K HDMI 2Ports Splitter
Color: Black
Overview:
HDMI-4K-S2 Item belongs to the HDMI signal distribution product. This is an ultra high definition
HDMI splitter supporting 3D and 4K*2K resolution. The ultra HD signal can be easily allocated to
multiple monitors that support Ultra HD signals.
The front and rear end of this product can connect to splitter, matrix and extender etc. And the picture
effect have no degradation and with good stability. When playing HD video without pause, delay and
trailing as well as perfectly supports 3D to make you enjoy three-dimensional picture.
It is widely used for video advertising, monitoring, information release, security system, multimedia
teaching system, bank, metro, computer room and long distance transmission management etc..
Support the highest signal format: 4K*2K 30Hz, support 3D, backward compatible with 1080P
- HDMI signal bandwidth: 340MHz / 3.4Gbps
- HDMI version 1.4, HDCP 1.4 compliant
- Support EDID automatic identification
- Support Blu-ray BLU-ray DVD24 / 50 / 60fs / HD-DVD / XVYCC
- Audio format DTS-HD, Dolby-trueHD, LPCM7.1, DTS, DOLBY-AC3,DSD, HD (HBR)
- There is a signal connection indicator, and the corresponding channel has a signal output thatwill automatically light up.
| Video | protocol supported | HDCP 1.4 |
| Pixel bandwidth | 340MHz，full digital | |
| Interface bandwidth | total bandwidth 10Gbps | |
| Maximum support resolution | 4K*2K@30Hz | |
| Interface | HDMI-A | |
| Impedance | 100Ω | |
| Support | EDID | support |
| Audio format | DTS-HD/Dolby-trueHD/LPCM7.1/DTS/DOLBY-AC3/DSD/HD(HBR) | |
| HDMI input distance | 24AWG(15m) | |
| HDMI output distance | 24AWG (10m) | |
| Others | Power supply | power supply adapters：DC 5V/1A |
| Maximum power consumption | 3.8W | |
| Working temperature | -5℃ ~ +70℃ | |
| Working humidity | 5% ~ 90% |
